1.1.2 polymer fluid loss additive

There are many kinds of synthetic polymer fluid loss additives with excellent performance, which are incomparable with some natural products, so they have become the focus of development by researchers all over the world.

1) Nonionic polymer

PVA (polyvinyl alcohol) system is a kind of non-ionic fluid loss additive widely used in China, which has unique advantages. Typical products such as zoranoc g80s. The operating temperature of the system can reach 95 ℃. Above this temperature, the crosslinking bond will be destroyed and the filtration reduction performance will be worse. In addition, the salt resistance (NaCI) of the system is poor, and the salt resistance is usually less than 5%. In order to improve the poor temperature and salt resistance of PVA system. PVA can be modified by chemical crosslinking method, such as condensation reaction of alcohol group of PVA with aldehydes or acids to obtain partially crosslinked PVA. The chemical crosslinked PVA can be used alone without crosslinking agent such as borax. The temperature resistance can reach 120 ℃, salt resistance can reach 8%, and the filtration rate can be controlled below 50ml

2) Anionic polymer

Anionic polymer is a kind of fluid loss additive with the most widely studied products at home and abroad. Its comonomers include nonionic and anionic monomers. Non ionic monomers mainly include am (acrylamide), NVP (N-vinylpyrrolidone), NNDMA (n, N-dimethylacrylamide), St (styrene), VI (VINYLIMIDAZOLE), VFA (vinylformamide), VP (vinylpyridine), vmaa (n-methyl-n-vinylacetamide), etc. Among these monomers, am is easy to hydrolyze, so the content of am in the copolymer should not be too much: NNDMA introduces a group that is not easy to hydrolyze, and its high temperature resistance is obviously enhanced, but this kind of monomer is expensive, and it is still in the pilot stage in China. There are two kinds of anionic monomers, one is sulfonate monomer, such as amps (2-acrylamido-2-methylpropanesulfonic acid), SS (styrene sulfonate), vs (ethylene sulfonate), PS (propylene sulfonate); The other is carboxylate monomer, such as AA (acrylic acid), MAA (methacrylic acid), hea (hydroxyethyl acrylic acid) IA (itaconic acid), etc. Amps is widely used due to its high temperature and salt tolerance, high polymerization activity and large-scale production in China.

Foreign developed products such as halad-344, halad-413, halad-4, halad-700 of Halliburton company, FL-32, FL-33 of BJ company all belong to this kind of products. In recent years, China has strengthened the research in this area and made a lot of research results, such as ZOC-86L of ZORANOC.
